Planar PXN2200 - Technical Information

16
Technical Information
Technical Specification
Panel 21.5” TFT (with LED backlight)
Power Management Normal On: 22 Watts (typical), 24 Watts (maximum)
ECO Mode 1 On: 13.4 Watts (typical)
ECO Mode 2 On: 11.3 Watts (typical)
ECO Mode 3 On: 8.5 Watts (typical)
Standby Mode: < 0.5 Watt
Off: < 0.5 Watt
Displayable Resolution Full HD 1920 x 1080 max. Vertical Frequency 60Hz max.
Pixel Dimension 0.24795 x 0.24795mm
Display Color 16.7M
Tilt -3°~20°
Active Display Area 18.74" x 10.54" (476.064 mm x 267.786 mm)
Temperature Operating: 0°C ~ + 40°C
Storage: -20°C ~ + 60°C
Compliance FCC-B, CE, UL/cUL
Power Input Voltage AC100-240 V
Speaker 2W x 2
