FACTORY PRESET TIMING TABLE
Preset HDMI/Displayport/VGA
Standard Resolution (Hz) HDMI DP VGA
VGA 640×480@60 V V V
VGA 640×480@67 V V V
VGA 640×480@72 V V V
VGA 640×480@75 V V V
DOS 720x400@70H V V V
SVGA 800x600@56 V V V
SVGA 800x600@60 V V V
SVGA 800x600@72 V V V
SVGA 800x600@75 V V V
XGA 1024×768@60 V V V
XGA 1024×768@70 V V V
XGA 1024×768@72 V V V
XGA 1024×768@75 V V V
SXGA 1280×800@60 V V V
SXGA 1280×1024@60 V V V
SXGA 1280×1024@70 V V V
SXGA 1280×1024@75 V V V
WXGA+ 1440×900@60 V V V
WXGA+ 1440×900@75 V V V
WSXGA+ 1680×1050@60 V V V
HD 1280x720@60Hz V V V
HD 1366x768@60Hz V V V
HD+ 1600x900@60Hz V V V
FHD 1920x1080@60Hz V V V
FHD 1920x1080@75Hz(RB) V V V
Video Timing Resolution
Standard Resolution (Hz) HDMI DP
480p 640x480 P59.94/60Hz(4:3) V V
480p 720x480 P59.94/60Hz(4:3) V V
480p 720x480 P59.94/60Hz(16:9) V V
576p 720x576 P50Hz(4:3) V V
576p 720x576 P50Hz(16:9) V V
720p 1280x720 P50Hz(16:9) V V
720p 1280x720 P59.94/60Hz(16:9) V V
1080p 1920x1080 P50Hz(16:9) V V
1080p 1920x1080 P59.94/60Hz(16:9) V V
