E - 14
Aux-In Mode
Your can connect up to 1 AV device, press the
SOURCE button to enter into the Aux-In mode:
Aux - 1 IN = Front panel Aux in
AV - 2 IN = RCA back of unit
TIPS
If there is no any external AV System input,
then the TFT will be show “ NO VIDEO
SIGNAL”.
Aux -1 In
AV - 2 In
This unit is allowed to connect with external
Audio/Video system such like Digital Camera
or Game Console. User can connect the
external Audio/Video system thru the Aux-In
jack on front panel.
Connect the external signal to the RCA line in
jack located at the rear of the unit , then press
SOURCE button to select AV -2 In.
Select the AV Mode
Connect the Aux-In
Ground
Left Track
Right Track
Connect the external signal to Aux-In jack
located at the front of the panel, then press
Source button to select Aux-In mode. Press
Mode Button again to cancel Aux-In mode and
retrun to previous mode.
