Planet GS-5220-16S8C Quick Installation Guide

10
5. Starting Web Management
The following shows how to start up the Web Management of the Industrial
Managed Switch. Note the Industrial Managed Switchis congured through an
Ethernet connection. Please make sure the manager PC must be set to the
same IP subnet address as shown in Figure 5-1.
For example, the default IP address of the Industrial Managed Switch is
192.168.0.100,thenthemanagerPCshouldbesetto192.168.0.x(wherex
is a number between 1 and 254, except 100), and the default subnet mask is
255.255.255.0.
PC / Workstation
with Web Browser
192.168.0.x
Managed Switch
RJ45/UTP Cable
IP Address: 192.168.0.100
Figure 5-1: IP Management Diagram
