A.3 Fiber Optic Cable Connection Parameter
The wiring details are shown below:
100FX Fiber Optic Cables:
Standard Fiber Type CableSpecications
100BASE-FX
(1300nm)
Multi-mode
50/125μmor
62.5/125μm
100BASE-FX
(1310nm)
Multi-mode
50/125μmor
62.5/125μm
Single-mode 9/125μm
100BASE-BX-U
(TX:1310/RX:1550)
100BASE-BX-D
(TX:1550/RX:1310)
Single-mode 9/125μm
1000X Fiber Optic Cables:
Standard Fiber Type CableSpecications
1000BASE-SX
(850nm)
Multi-mode 50/125μmor62.5/125μm
1000BASE-LX
(1300nm)
Multi-mode 50/125μmor62.5/125μm
Single-mode 9/125μm
