Planet ISW-501T User Manual

10
4.ProductSpecications
Model ISW-501T ISW-801T
HardwareSpecications
Hardware Version 3
Copper Ports
5 x 10/100BASE-TX RJ45
TP
auto-MDI/MDI-X,
auto negotiation
8 x 10/100BASE-TX RJ45
TP
auto-MDI/MDI-X,
auto negotiation
Connector
Removable 6-pin terminal block
Pin 1/2 for Power 1; Pin 3/4 for fault alarm;
Pin 5/6 for Power 2
Alarm
Provides one relay output for power failure;
Alarm relay current carry ability: 1A @ DC 24V
LED
3 x LED for system and power:
 Green: DC Power 1
 Green: DC Power 2
 Red: Power Alarm
1 x LED for each copper port:
 Green: 10/100Mbps LNK/ACT
ESD Protection 6KV
EFT Protection 6KV
Power Requirements
12~48V DC, redundant power with polarity reverse
protection function, 24V AC power support
Power Consumption/
Dissipation
Max. 0.9 watts/3.07BTU
(Power on without any
connection)
Max. 1.6 watts/5.45BTU
(Ethernet full loading)
Max. 0.9 watts/3.07BTU
(Power on without any
connection)
Max. 2.1 watts/7.16BTU
(Ethernet full loading)
Installation DIN-rail kit and wall-mount ear
Enclosure IP30-rated metal case
Dimensions (W x D x H) 32 x 87 x 135mm
Weight 400g 428g
SwitchSpecications
Switch Processing Scheme Store-and-Forward

Planet ISW-501T Specifications

General

Brand	Planet
Model	ISW-501T
Category	Switch
Language	English
