Planet ISW-501T User Manual

11
Address Table 1K
SharedDataBuer 448K bits
Flow Control
Back pressure for half duplex,
IEEE 802.3x pause frame for full duplex
Switch Fabric 1Gbps 1.6Gbps
Throughput
(packet per second)
0.74Mpps 1.19Mpps
Network Cables
10/100BASE-TX
Cat. 3, 4, 5, 5e, 6 UTP cable (max. 100 meters)
EIA/TIA-568 100-ohm STP (max. 100 meters)
Standards Conformance
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3x Full Duplex Flow Control
IEEE802.3azEnergyEcientEthernet
PROFINET protocol
Regulatory Compliance FCC Part 15 Class A, CE
Stability Testing
IEC60068-2-32 (free fall)
IEC60068-2-27 (shock)
IEC60068-2-6 (vibration)
Environment
Temperature
Operating: -40~75 degrees C
Storage: -40~75 degrees C
Humidity
Operating: 5% to 95%, Storage:
5% to 95% (non-condensing)
