3. Installation
This section describes the functionalities of the Industrial Ethernet Switch’s
components and guides you to installing it on the DIN rail and wall. Please read this
chapter completely before continuing.
This following pictures show how to install the device. However, the
device in the picture is not ISW-501T or ISW-801T.
3.1 DIN-rail Mounting Installation
1
2
3.2 Wall-mount Plate Mounting
To Next Page
