7
1. The wire gauge for the terminal block should be in the range between
12 and 24 AWG.
2. Alarm relay circuit accepts up to 24V, 1A current (max.).
2.6 Grounding the Device
Users MUST complete grounding wired with the device; otherwise, a sudden
lightning could cause fatal damage to the device.
Max. Fault Alarm Loading:24V, 1A.
DC Input: 12-48V
, 1.2A max.
AC Input: 24V
, 1.1A max.
Alarm
V1+ V2+
PWR2PWR1
1 2 3 4 5 6
Earth Ground
EMD (Lightning) DAMAGE IS NOT CONVERED UNDER WARRANTY.
To Next Page
