Planet MGSW-24160F Quick Installation Guide

3
1. Package Contents
Thank you for purchasing PLANET L2+ Managed Metro Ethernet Switch.
The description of this model is as follows:
Model Description
MGSW-24160F
L2+ 8-Port 10/100/1000T + 12-Port 100/1000X SFP +
4-Port 10G SFP+ Managed Metro Ethernet Switch
In this guide, the term “Managed Metro Switch” refers specically to the
MGSW-24160F.
Open the box of the Managed Metro Switch and carefully unpack it.
The box should contain the following items:
z The Managed Metro Switch x 1
z Quick Installation Guide Sheet x 1
z RJ45 to RS232 Console Cable x 1
z Rack-mountAccessoryKitx1
z ACPowerCordx1
z Dust Cap
Model RJ45 Dust Caps SFP Dust Caps
MGSW-24160F 8 16
If any item is found missing or damaged, please contact your local reseller for
replacement.

Planet MGSW-24160F Specifications

General

Console port	RS-232
Compatible memory cards	Not supported
SFP module slots quantity	16
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Private VLAN, Protocol-based VLAN, Port-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-FX, 100BASE-TX, 100BASE-T, 1000BASE-T, 1000BASE-TX
MAC address auto-learning supported	Yes
Throughput	35.6 Mpps
Jumbo frames	10000
MAC address table	16000 entries
Form factor	1U
Product color	Blue
Number of fans	2 fan(s)
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	38 W
Number of multicast groups filtered	255
Switch type	Managed
Switch layer	L2+
DHCP features	DHCP server, DHCP client
Security algorithms	SNMP, SSH, SSL/TLS
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Transmission distance (max)	120 km
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	200 mm
Width	440 mm
Height	44.5 mm
Weight	3000 g
