802.3af PoE SIP IP Phone
VIP-256PT
Package Content
‧ SIP IP Phone unit
‧ Power Adapter
‧ Quick Installation Guide
‧ CD-ROM containing the on-line manual.
‧ RJ-45 cable x1
Physical Details
The following figure illustrates the front/rear panel of IP Phone.
Front View and Keypad function
Keypad Description
Handset top cradle For the placement of handset (Receiver end)
Hook switch For hang-up and hang-off of handset
Cradle latch To prevent the handset from dropping when it is wall-mounted.
Handset bottom cradle For the placement of handset (Transmitter end)
Handset cord port RJ-11 jack on the left side of the IP phone
1
Headset wire port RJ-11 jack on the bottom of the handset
7
2
6
5
4
3
1
12
To Next Page
