Appendix A Specification
Standard IEEE 802.11g / 802.11b
Frequency Band 2.400~2.4835GHz
Transfer Rate 802.11g: 54/48/36/24/18/12/9/6Mbps
802.11b: 11/5.5/2/1Mbps
Modulation OFDM, CCK, DQPSK and DBPSK
Sensitivity
11g @ PER < 10%
54Mbps: -71.46 dBm
48Mbps: -73.1 dBm
36Mbps: -75 dBm
24Mbps: -77 dBm
18Mbps: -79.1 dBm
12Mbps: -81.1 dBm
9Mbps: -83.5 dBm
6Mbps: -85.52 dBm
11b @ PER < 8%
11Mbps: -82 dBm
5.5Mbps: -85.7dBm
2Mbps: -87 dBm
1Mbps: -91.5 dBm
Radio Technology Direct Sequence Spread Spectrum (DSSS)
Antenna Detachable dipole antenna
Transmit Power 18dBm (max.)
LAN Interface 5-port RJ-45 UTP, Auto-MDI/MDI-X
Cabling Category 5/5e or above, 4-pair
LED Indicators PWR, WLAN, 5 x LNK/ACT, 5 x ACT
Power 12V DC, 1A
Temperature
0 ~ 55°C (Operating)
Humidity 10 ~ 90%, non-condensing (Operating)
Dimension 190 x 98 x 35 (mm)
Weight 300g
Emission FCC Class B, CE-mark
