Planet WBS-512AC User Manual

User Manual of WBS-512AC
-6-
Product Specifications
Product
WBS-512AC
900Mbps Outdoor Wireless CPE Wave 2.0, MU-MIMO
Hardware
Standard Support
IEEE 802.11a/n/ac
IEEE 802.11i
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x flow control
IEEE 802.11k, 802.11v, and 802.11r
Dimensions (W x D x H)
87 x 38 x 260mm
Weight
405g
Power Requirements
48V DC IN, 0.5A, IEEE 802.3 at PoE+ or
12V DC IN, 1.0A from DC Jack
Power Consumption (max.)
< 10W
Interface
Wireless IEEE 802.11a/n/ac, 2T2R
PoE: 1 x 10/100/1000BASE-TX, auto-MDI/MDIX, 802.3 at PoE In
LAN: 1x 10/100/1000BASE-TX, auto-MDI/MDIX
Button
Reset/Pair button, PtP Switch
Antenna
Built-in 14dBi directional antenna with dual polarization
Half-power beam width
Vertical H: 70 V: 15
Horizontal H: 50 V: 15
Data Rate
IEEE 802.11a: up to 54Mbps
IEEE 802.11n (20MHz): up to 150Mbps
IEEE 802.11n (40MHz): up to 300Mbps
IEEE 802.11ac (80MHz): up to 867Mbps
Media Access Control
CSMA/CA
Modulation
802.11 a/n/ac: OFDM (BPSK / QPSK / 16QAM / 64QAM / 256QAM)
Frequency Band
FCC: 5.180~5.240GHz, 5.745~5.825GHz
ETSI: 5.180~5.700GHz
Operating Channels
FCC: 36, 40, 44, 48, 149, 153, 157, 161, 165 (9 channels)
ETSI: 36, 40, 44, 48, 100, 104, 108, 112, 116, 132, 136, 140 (12 channels)
5GHz channel list will vary in different countries according to their regulations.
Max. Transmit Power (dBm)
FCC: up to 25 ± 1dBm
ETSI: < 20dBm (EIRP)
Receiver Sensitivity (dBm)
Network Mode Data Rate Receive Sensitivity (dBm)
802.11a
6Mbps -92
54Mbps -75
802.11n HT20
MCS0/MCS8 -91
MCS7/MCS15 -72
