User Manual of WDRT-731U
-6-
1.4 Product Specification
Product
WDRT-731U
300Mbps Dual-Band 802.11n Wireless Gigabit Router
Hardware Specification
WAN Port: 1 x 10/100/1000Mbps Auto MDI/MDI-X RJ45 port
LAN Port: 3 x 10/100/1000Mbps Auto MDI/MDI-X RJ45 ports (LAN1~3)
IPTV Port: 1 x 10/100/1000Mbps Auto MDI/MDI-X RJ45 port (LAN4)
Interface
USB Port : USB 2.0, Type-A, 5V DC/0.5A Output
Gain: 2 x 5dBi fixed antenna
Antenna
Orientation: Omni-directional
Reset / WPS Button
Reset / WPS button at rear panel
 Press for about 7 seconds to reset the device to factory default.
 Press for 1 second to activate WPS function.
LED Indicators
PWR/SYS, WLAN (2.4G & 5G) x 2
WAN (Link & 1000Mbps) x 1
LAN (Link & 1000Mbps) x 3
IPTV (Link & 1000Mbps) x 1
USB, WPS
Material
Plastic
Dimension (WxDxH)
171.61 x 111.16 x 25.47 mm (W x D x H)
Weight
250g
Power Requirement
12V DC, 1A
Wireless interface Specification
Standard
Compliance with IEEE 802.11a/b/g/n
Frequency Band
Simultaneous 2.4 GHz and 5 GHz
2.4GHz: 2.412~2.484GHz
5GHz: 5.180~5.825GHz
Transmission
Distance
Indoor up to 100m
Outdoor up to 300m (it is limited to the environment)
RF Power
(Intentional Radiator)
2.4GHz:
11b: 17±1dBm
11g: 14.5±1.5dBm
11n: 12.5±1.5dBm
5GHz:
11a: 12±1.5dBm
11n: 12±1.5dBm
Wireless Management Features
Wireless Modes
 AP
 WDS PtP
 WDS PtMP
