IEEE 802.11b/g, IEEE 802.11n HT20: 11 Channels
IEEE 802.11n HT40: 7 Channels
2.412~2.462GHz
User’s Manual of WNRT-617
-3-
1.4 Product Specification
Product
WNRT-617
150Mbps 802.11n Wireless Broadband Router
Hardware Specification
WAN Port: 1 x 10/100Mbps Auto MDI/MDI-X RJ45 port
Interface
LAN Port: 4 x 10/100Mbps Auto MDI/MDI-X RJ45 ports
Gain: 1 x Fixed 5dBi Antenna
Antenna
Orientation: Omni-directional
Power Button Power On/Off button at rear panel
WPS / Reset Button
WPS / Reset button at front panel
Push for above 5 seconds to reset to factory default setting
LED Indicators PWR, SYS, WLAN, LAN x 4, WAN, WPS with green light
Material Plastic
Wireless Interface Specification
Standard Compliance with IEEE 802.11b/g/n
Frequency Band
Extend Frequency
DSSS
Modulation Type
DBPSK, DQPSK, QPSK, CCK and OFDM (BPSK/QPSK/16-QAM/ 64-QAM)
Data Transmission
Rates
11n: 135/121.5/108/81/54/40.5/27/13.5Mbps
130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps (Dynamic)
11g: 54/48/36/24/18/12/9/6Mbps (Dynamic)
11b: 11/5.5/2/1Mbps (Dynamic)
Transmission
Distance
Indoor up to 100m
Outdoor up to 300m (it is limited to the environment)
Channel
Receive Sensitivity
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Wireless Management Features
Wireless Operation
Mode
AP, WDS (AP+Bridge)
Encryption Security
WEP (64/128/152-bit) encryption security
22.65 dBm (max)
RF Power (peak)
