12 | Dimmer User Manual
Step1. When you hit Enter on the
"Program Day: xxx" line using the "UP/
DOWN" keys as described above you
will come to a menu to program the
lighting period for that day. You may
program up to 99 unique lighting
periods in a single day. The Lighting
Period View/Interface will appear as
shown below:
Light Period:01
Zone 1
Fig. 15: Lighting Period window
Step2. When you hit Enter on the
"Light Period: xx" line using the "UP/
DOWN" keys as described above you
will come to a menu to program the
"Lighting Period" for that period of the
program day.
The Lighting Period Interface is shown
below:
Start Ti:00:00am
End Time:00:01am
Zone 1
Fig. 16: Lighting Period window
Start Time of day for the rst period of
each program day is a l ways 00:00am.
This will be the rst period start time.
Now you can use the navigation
buttons to change the period end
time for each period. You can use the
"LEFT" and "RIGHT" navigation buttons
to move from one number eld to
the next and the "UP" and "DOWN"
navigation buttons to change the
actual values. Once you are nished
setting the end time you hit enter.
When you come to the next time
setting the start time will now match
the end time for the previous period
setting that you entered.
Step3. Hit "ENTER" to move to the
setting the light intensity level for the
Lighting Period.
The lighting intensity menu interface is
found below:
Intensity : 10%
Zone 1
Fig. 17: Lighting intensity setting window
You can use the navigation "UP" and
"DOWN" buttons to set the desired
lighting intensity level. This can be
anything between 0 and 100%. 0% is
lights o and 100% is lights 100% on.
Step4. Once you hit "ENTER" on the
Lighting intensity level the user will
now be prompted to set the lighting
period transition.
