Fig. 18: Lighting period transition
interface window
The user will use the ''LEFT' and "RIGHT"
navigation buttons to change the
selected time setting to modify. The
user will use the "UP" and "DOWN"
navigation buttons to move the time
up and down.
For example, if the user is going from
lights o or "0%" intensity level in one
lighting period, to a 100% level, then
they could choose a transition period
of 30 minutes so that the change from
0% lighting intensity to 100% lighting
intensity is a gradual one. In this
case, the controller will automatically
increase the lighting intensity level by
100/30 or 3% every minute.
Once the desired transition period
time is set the user should hit "ENTER"
to complete the programming of that
lighting period.
Then the program will automatically
take the user back to the "Lighting
Period"
Interface menu to set the next lighting
period. When any lighting period
which is being programmed for a given
program day is set with an END TIME
of 11:59 PM then the interface moves
to the NEXT PROGRAM DAY interface
automatically after the transition time
is set for that period: After the user hits
"ENTER" in the transition time window
when the period end time is 11:59 PM
then the interface will automatically
move to the next program day inter
face (as shown). The example shown
above assumes that the user has just
completed setting the transition time
for the light period ending at 11:59 PM
of Program Day 001.
Program Day:002
Keep
Reset Prog Day
Pre Day Pro
Zone 1
The user can always select the "EXIT"
button to exit the editing of any program
day.
● Program Mode
When selecting "Program Mode"
from the main screen, the screen that
appears looks like this:
Manual
Slave
Master
Fig. 19: Lighting period transition
interface window
Use the navigation "UP" and "DOWN"
keys to move to the selection you
