PlayActive MINI Beachcomber - Assembly - Power Supply; Power Supply Connection Steps

2
1
Connect the Power Supply │ 12
1. Plug the Vehicle Connector into the Motor Connector on body as shown
above. Repeat for the other side.
2. Plug the Red fuse connector into the terminal on battery.
Vehicle
connector
Motor connector
Fuse box
Battery
