1. Turn over the vehicle body and cut off the plastic tie on the frotn wheel axle with
scissors.
2. Remove the M5x16 screw, washer and nut from the front wheel axle.
3. Adjust the wheel axle so that the axle is in the correct positon as shown in
picture at right; then reinsert the M5x16 screw and washer as shown, making
sure the M5x16 screw goes through the holes in the metal plates A and B
(ensure plate B sits over plate A as shown with stopper, to prevent fingers
becoming trapped while steering), attach the locknut and tighten securely.
Attach the Front Axle │ 5
A
B
Stopper
M5x16 screw
Ø5 locknut
To Next Page
