By pressing the CTRL 1 and CTRL 2 buttons, the Modulation Sources to the Oscillator are selected. Each press moves
from Mod Envelope, to LFO 1, to LFO 2 to No Modulation When No Modulation is selected, only the static value of the
MOD 1 and MOD 2 knobs are used to modulate. Notice the MOD 1 and MOD 2 LED brightness changes to reect the
value of the MOD 1 and MOD 2 inputs.
The FILTER MOD button selects the modulation source for the Filter in the same way. Notice the lower LED next to
the FILTER MOD button changes brightness to reect the value of the FILTER MOD inputs.
Notice each time the CTRL 1, CTRL 2 or FILTER MOD buttons are pressed, the LEDs animate to point to which
modulation source was selected.
Note that a single modulation can be applied to multiple destinations. For example, LFO 1 can be applied to MOD 1,
MOD 2 and FILTER MOD all at the same time.
AMPLIFIER
After the lter, the signal moves through the amplier envelope. This envelope controls how long the sound stays
on, or “releases” after a note ends. With the AMP RELEASE knob set to the minimum value (counter-clockwise), the
sound ends instantly at the end of the musical note. If you increase the AMP RELEASE knob (clockwise), the sound
lingers on and slowly decays at the end of the note.
EFFECTS
The After Dark includes a multi-tap stereo delay eect. This gives the sound a rich, spacey quality. The amount of
delay can be controlled by holding down the CTRL 1 button. The LED display will direct you to the right of the unit,
where you can use the FILTER lever to adjust the amount of delay in the sound.
OUTPUT
The VOLUME knob is the last stage in the synthesis engine, it controls the loudness of the sound.
