18
S
PECIFICATIONS
310-WATTS CONTINUOUS PER CHANNEL INTO 8 OHMS.
BOTH CHANNELS DRIVEN FROM 20Hz TO 20kHz.
FREQUENCY RESPONSE: 20Hz to 20kHz ±0.2dB. -3dB at 1Hz and -3dB at 70kHz.
DISTORTION: Typically <0.05% THD at rated power. 0.1% THD and IM worst case prior to clipping.
CURRENT OUTPUT: 50A short duration peak per channel. Fuse protected.
RISE TIME: Typically 5μs.
PHASE RESPONSE: +0° at 20Hz and -14° at 20kHz.
HUM & NOISE: 100dB below rated output 20Hz to 20kHz A-weighted.
INPUT IMPEDANCE: 47kΩ.
GAIN ON RCA INPUTS: 32dB
GAIN ON BALANCED INPUTS: 38dB
HEIGHT: 220mm (8 3/4")
WIDTH: 500mm (19 3/4")
DEPTH: 455mm (18")
WEIGHT: 38kg (83lbs)
