Collator Series 300/400 Operator Manual 5-1
5. Maintenance
5.1 Cleaning feed rollers and paper separator pad
1 Remove the feed roller assembly shaft by pressing it
to the left side.
The right end of the feed roller assembly will now be
released and the assembly can be removed.
2 Clean the feed rollers and the separator pad with an
alcohol based liquid.
paper separator pad
feed rollers
Press to the left
Lift out this side
