Collator Series 300/400 Operator Manual 4-1
4. Operator instructions
4.1 Load paper
4.2 Operating the collator
1 Make sure that the sheets are well fanned to avoid
miss feeds or double feeds.
2 Align the sheets well to achive a reliable collating
operation and good stacking result.
3 Make sure that the ink has dryed out well.
4 Press the load lever downwards to release the bins.
5 Load the sheets into the bins.
6 Move the adjustable sidwe up against the sheets until
there is no clearance.
7 Raise the load lever to actuate the feed rollers.
1 Set the on/off switch to on position. The counter display
willshow”HEJ”toconrmthatallsystemsareOK.
2 Select output mode:
- Offset/straight stacking mode.
- Third party mode.
3 Select stacking mode if set to stacking:
- Straight stacking.
- Offset stacking.
4 Set the adjustable stacker guide (left) to the selected
paper size.
5 Set the adjustable stacker guide (front) to the paper
size.
6 Press test/calibration button. The collator will adjust
the number of bins used and the paper quality in each
bin and is now ready for operation. Check the result to
makesurethatitisOKandpressstart.
