T10137 Jan 2003
Collator Series 300/400 Operator Manual i
Table of contents
1. Introduction page
1.1 Operational safety 1-1
2. Installation
2.1 Installation 2-1
3. Getting to know the collator
3.1 Main components 3-1
3.2 The control panel 3-2
4. Operator instructions
4.1 Load paper 4-1
4.2 Operating the collator 4-1
4.3 Bin indicators 4-2
4.4 Correcting counter and stacker position 4-2
4.5 Zero setting total counter 4-2
4.6 Programming preset counter 4-3
and sheet insertion program
4.7 LED indications, third party device 4-3
4.8 Disabling stacker motion 4-4
4.9 Collator speed adjustment 4-4
4.10 Disengaging bin´s with defective sensors 4-4
5. Maintenance
5.1 Cleaning feed rollers and paper separator pad 5-1
6. Problem solving
6.1 Problem solving 6-1
7. Specications
7.1 Specications 7-1
