Luxor menus
Six dierent menus may be selected by the user on Luxor’s organic LED display. These menus
include battery percentage, time remaining, electrical, health & charge mode, throw, and
lumens.
Battery percentage: The battery percentage menu will display the remaining battery capacity
as a percentage of Luxor’s maximum battery capacity numerically and graphically. The remain-
ing battery capacity will also be displayed in mAh.
Timeremaining:In the time remaining menu, Time to Discharge, Time to Charge, or Fully
Charged will be displayed. During normal operation, the Time to Discharge will be displayed,
showing the amount of time left before Luxor needs to be charged. If Luxor is being charged,
the Time to Charge will be displayed, showing the amount of time Luxor needs to be charged to
reach full capacity. If Luxor has reached full capacity, Fully Charged will be displayed.
Electrical:The electrical menu contains the voltage, current, and power readings of Luxor’s bat-
tery. NOTE: If your screen is on but the LEDs are o, you should expect to see a low current of
0.05A or less.
Health&chargemode:The health & charge mode menu displays the condition (new, good, ok,
poor, bad, or replace) of Luxor’s battery, as well as which charge mode is activated.
NOTE: Please note that LiPo batteries operate better at lower temperatures.
Throw:The throw menu contains the distance in meters that the beam light is emitting.
Lumens:The lumens menu shows the total amount of light emitted in lumens. Additionally, the
Lumens menu graphically shows what percentage of maximum light output is being emitted
from each set of LEDs (beam, ood, lantern).
Charging your Luxor
1. Insert the USB male A end of your
charging cable into a USB power source.
2. If the waterproof tail cap is on, unscrew
the tail cap seal and remove the tail cap.
3. Connect the micro USB end of your
charging cable into Luxor’s micro USB
port.
NOTE: Luxor will still charge if it is o or
locked.
