Connection of a 2-wire
transmitter:
OPERATION
I
display of maximum value
D
display of minimum value
ID,(I at first)
reset maximum value
DI,(D at first)
reset minimum value
M more than 5 seconds parameter level
F
function configurable (Ä page 15)
With the channel selector switch connected:
MI,(M at first)
switch-over to next channel
MD,(M at first)
switch-over to previous channel
PARAMETER SETTING
Press key M during more than 5 seconds for changing over to the parameter level.
+ The folded page at the end of these operating instructions gives a
survey of the parameter level.
6
9499-040-24701
