specifications
wafer 1
™
wafer 2
™
Freq response 50Hz-25kHz 40Hz-25kHz
Sensitivity 87dB 1w 1m 90dB 1w 1m
Impedance 8 Ohms 8 Ohms
Drive Units LF 140mm (5
1
/2”) LF 170mm (6
1
/2”)
HF 2 x 27mm Soft dome HF 2 x 27mm Soft dome
Input connectors 1 pair 4mm sockets 1 pair 4mm sockets
Dimensions H x W x D H x W x D
Cabinet 500 x 235 x 100mm 575 x 355 x 100mm
(19.7 x 9.3 x 4 inches) (22.6 x 14 x 4 inches)
Cabinet with grille 516 x 267 x 108mm 591 x 387 x 108mm
(20.3 x 10.51 x 4.25 inches) (23.27 x 15.24 x 4.25 inches)
Weight 5kg (11 lbs) 6.6kg (14.5 lbs)
Colours White, Black White, Black
wafer1
™
(Two way on-wall monitor)
wafer2
™
(Larger, Two way
on-wall monitor)
loudspeaker user-guide
