PNI DK220 - Page 23

23 - User manual
Connection examples for one and two doors
Access control for one door with Silvercloud YE910 or Silvercloud
YS810 electromagnetic lock and PNI ST3.4A power supply.
12V
Orange
Purple Blue
Grey
Brown
Yellow
Black
Red
White Green
Pink Pink Red
Black
Yellow
Brown
Grey
Blue Purple
Orange
D0 D1
AC1(+12V)
GND OPEN1(BZ)
A_IN1(LED) ALARM1-
NO1
COM
NC1
NC2 COM2
NO2
ALARM2 D_IN2
OPEN2 AC2
ALARM+
BELL_B
BELL_A
Power supply PNI ST3.4A
Electric lock
Silvercloud YE910
Electric lock
SilverCloud YS810
