POCLAIN HYDRAULICS
103 DOC-REPAIR-MS25-MS125-FR-EN 800378131M
Mandrin utilisé pour
compresser la rondelle
élastique du frein.
Mandrel used to
compress the brake
spring washer.
F04-F05-F07 F08-F09
MX
M12 M16
F04-F05-F07 F08-F09
ØA / A dia
115 [4.53] 150 [5.90]
ØB / B dia
125
[4.93]
160
[6.30]
C
100
[3.93]
100
[3.93]
ØD / D dia
35
[1.37]
35
[1.37]
E
10
[0.39]
10
[0.39]
F
30
[1.18]
30
[1.18]
G
10
[0.39]
10
[0.39]
ØB / B dia
ØA / A dia
F
G
ØD
D dia
C
E
MX
Moletage
Milling
Mandrin pour remonter
la coiffe du frein.
Mandrel for reassembling the
brake cover.
F04 F05 F07
MX
M12
ØA / A dia
151 [5.94]
ØB / B dia
159
[6.25]
C
100
[3.93]
ØD / D dia
35
[1.37]
E
10
[0.39]
F
30
[1.18]
G
10
[0.39]
ØB / B dia
ØA / A dia
F
G
ØD
D dia
C
E
MX
Moletage
Milling
Mandrin pour remonter
la coiffe du frein.
Mandrel for reassembling the
brake cover.
F08 F09
MX
M16
ØA / A dia
151 [5.94]
ØB / B dia
195
[7.67]
C
100
[3.93]
ØD / D dia
35
[1.37]
E
10
[0.39]
F
30
[1.18]
G
10
[0.39]
ØB / B dia
ØA / A dia
F
G
ØD
D dia
C
E
MX
Moletage
Milling
