Use
Instructions for use
Settings
Instructions for use
• Adjusting the vertical position
The monitor is adjustable
in vertical position
from +24° to +85°.
It is not recommended
to use the monitor
with a setting below 35°.
Simply point the diuser
to the correct position
to perform the adjustment.
• Adjusting the horizontal position
The horizontal position
of the monitor is adjustable
from -26° to +26°.
Simply point the diuser
to the correct position
to perform the adjustment.
35°
85°
52°
26°
26°
