Presentation
Technical data
Characteristics
Technical data
DESIGNATION DESCRIPTION
Code • 18065
Body • Aluminium alloy, polyester coated
Outlet ball, ball valve, stabilizing leg, inlet ange,
stream shaper
• Aluminium alloy, hard anodisation
Screws, springs and axles • Stainless steel
Gaskets • Nitrile
Stabilizing legs pins • Tungsten carbide
Weight • 6.1 Kg
• Construction
DESIGNATION DESCRIPTION
Flow rate • 750 lpm @ 7 bar
Maximum working pressure • 16 bar
Test pressure • 25.5 bar
Monitor inlet
• 2.5’’ BSP male thread
Note: A coupling is available upon request. See our catalogue for more
information on couplings.
Monitor outlet • 1.5’’ BSP male thread
Vertical movement
• from +24° to +76°
• Output on multi-directional ball mounted
Horizontal movement
• from -26 to +26°
• Output on multi-directional ball mounted
Shut-o
• ball valve, quarter turn opening
• Waterway Ø 52 mm
Safety
• Shuto valve
• Locking pin for stabilizing legs
• Anchoring ring and strap
• General data
