POK Froggy - Parts List

POK SAS - 18 Cours Antoine Lavoisier - 10400 Nogent-sur-Seine - FRANCE
Phone: +33 (0)3 25 39 84 78 - Fax: +33 (0)3 25 39 84 90 - Email: export@pok-re.com - Web: www.pok-re.com
MOP_LMM_02144_EN_A - 13/03/2019 - Copyright© POK SAS - Illustrations are only informative
FROGGY - Portable monitor, 750 lpm FROGGY - Portable monitor, 750 lpm
18
Parts list
Bill of materials
MARK QTY DESCRIPTION CODE
1 1 BODY 18068
2 1 BALL 18069
3 1 SPACE TH.1 19552
4 1 CAP 18070
5 2 SPHERICAL PAD 18071
6 1 STREAM SHAPER 20021
7 1 BALL Ø52 2616
8 1 SQUARE FLANGE DN 65 - 2.5" BSP MALE 11920
9 1 VALVE AXLE 16188
10 1 FLAT HANDLE 14465
11 1 SCREW FOR VALVE AXLE 16189
12 1 LOWER AXLE 10517
13 1 LOWER AXLE SCREW 10518
14 2 STABILIZING LEGS AXLE 10876
15 12 SPRING WASHER 16644
16 1 LONG RIGHT STABILIZING LEG 17971
17 1 LONG LEFT STABILIZING LEG 17972
18 2 SPACER WASHER 10916
19 2 SHORT STABILIZING LEG 17973
20 1 BOTTOM PLATE 25671
21 4 PIN HOLDER 10867
22 1 LEGS LOCKING PIN SLEEVE 10901
23 1 LOCKING SPRING 10900
24 1 SAFETY PIN FOR STABILZING LEGS 10899
25 1 2 TURNS RING 2898
26 2 DRIVE PIN 20123
27 10 SCREW CHC M6-20
28 4 SCREW CHC M8-16 -
29 5 SCREW FHC M8-16
30 1 SCREW STHC TL M8-20
31 2 O’RING Ø64 x Ø4 -
32 2 GASKET FOR BALL Ø52 14800
33 2 O’RING R7 8207
34 2 O’RING N°12 8212
35 1 O'RING N°43 8243
36 1 O’RING R44
37 1 O’RING Ø117.07 X 3.53 16819
38 2 O’RING Ø101.2 X 3.53
39 4 PIN 10868
40 1 CARRYING HANDLE 10914
41 1 COVER FOR HANDLE 12021
42 1 SCREW CHC M10x35 -
43 1 WASHER W10 -
44 1 NUT H M10
