Polaris 120 Indy User Manual

80
SPECIFICATIONS
Capacities and Dimensions
Body Style Mini Indy
Rider/Weight Capacity 1/140 lbs. (63.5 kg) maximum
Dry Weight 147.5 lbs. (67 kg)
Fuel Tank Capacity .5 gal. (1.9 l)
Engine Oil Capacity 20 oz. (.6 l)
Height 31 in. (79 cm)
Length 75 in. (191 cm)
Width 34 in. (86 cm)
Track Length 69 in. (175 cm)
Track Width 10 in. (25 cm)
Brake Type Mechanical
Ski Center Distance 30 in. (76.2 cm)
Drive Clutch Type/Driven Clutch
Type
Centrifugal/Sprocket
Drive Chain Length #40DLX74
Suspension
Front Type IFS
IFS Shock Type Mini
Rear Type Mini Indy
Engine and Cooling
Engine Model Number EH122PM001G
Alternator Output 50 watt @ 3600 RPM
Bore x Stroke 60 x 43 mm
Displacement 121 cc
Carburetor/Throttle Body 1-Mikuni Tamperproofed
NOTE: These
carburetor settings are
to be used in
conjunction with the
jetting chart on the
following page, which
is based on the
recommended fuel
octane.
Carburetor Model BV18
Idle RPM +/- 100 1650
Rated Operating RPM 3600
Main Jet 70
Pilot Jet 50
Jet Needle N/A
Needle Jet N/A
Cutaway 170 Throttle Valve
Fuel Screw (from fully seated) 1.75 Turns; Non-adjustable
Pilot Air Jet 1.3 mm
Cooling Air
Cylinders 1
Ignition Timing 23° BTDC @ 3600 RPM
Ignition Type Flywheel Magneto (solid state)
Spark Plug/Gap NGK BR6ES/.028" (.70 mm)
Recommended Engine Oil PS-4 or PS-4 Plus
Recommended Fuel Octane Minimum 87 octane non-oxygenated or 89 octane
oxygenated
