1.11
SPECIFICATIONS
Table 1-59: Front Suspension
Suspension type IQ 42.5
IFS shocks Arvin/7043054
IFS spring rate lbs-in/kg-mm 120/2.1
Spring installed length in/cm 9.95/25.3
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/cm 2.25±.31/5.7±.79
Toe in/mm 0-.12/0-3.0
Table 1-60: M-10 Rear Suspension
Suspension type M-10 128
Front track shock (FTS) Fox/7043123*
FTS spring rate
lbs-in/kg-mm
160/2.9
FTS spring installed length
in/cm
8/20.3
Rear track shock Fox/7043190*
Lower outer spring
lbs-in/kg-mm
715/12.8
Lower inner spring
lbs-in/kg-mm
425/7.6
Upper spring
lbs-in/kg-mm
273/4.9
Rear travel in/cm 13/33
* notes that shock is rebuildable
Table 1-61: Dimensions
Width in/cm 48/121.9
Length in/cm 115/292.1
Height in/cm 53/134.6
Est dry weight lb/kg 524/237
Table 1-62: Electrical
Stator output 400w@4000RPM
Ignition timing @ 9.6-12.7%
throttle
16_@3500
Spark plug gap in/mm .025/.64
Spark plug Champion RN57YCC
