6.13
ENGINE
2. Remove the water pump cover (2) and gasket (3).
3. Remove the impeller nut and washer.
4. Remove the impeller.
5. With two flat head screw drivers pry the water pump seal
out by lifting up on the seal flange. This will crush the
flange upward.
6. Pry the mechanical seal out of the case.
NOTE: You will destroy the oil seal when you
remove it from the case. You will also mar up the
case while you are removing the mechanical seal.
This seal can not be reused.
7. Remove the oil seal by screwing in a screw into the oil seal
and pulling it out of the case.
1
2
3
