10.13
FRONT SUSPENSION/STEERING
Table 10-8: IQ Front Suspension
ITEM DESCRIPTION TORQUE SPECIFICATION / NOTES
1 Lower A-Arm pivot bolt
2 Flat washer Critical for spacing the bolt from the sway bar.
3 Pivot Shaft
4 Flanged nut 40 ft-lb (54Nm)
5 Pivot Bushing
6 Upper A-Arm pivot bolt
7 Pivot shaft
8 Flanged nut 40 ft-lb (54Nm)
9 Pivot Bushing
10 Upper control arm
11 Camber lock nut
12 Rod end bolt
13 Rod end
14 Flanged nut 35 ft-lb (47Nm)
15 Screw
16 Jam nut
17 Swaybar slide
18 Nylok nut
19 Nut 29ft-lb (39Nm)
20 Lower control arm
21 Bearing
22 Retaining ring
23 Washer
24 Bolt
25 Steering arm nut 29ft-lb (39Nm)
26 Steering arm
27 Washer
28 Spindle
29 Bushing ski pivot bushing
30 Pivot bushing
