11.8
REAR SUSPENSION
7043128 LH
7043129 RH
.405 14.75 4.5 2.5 6.72 80 3.40
7043130 RH
7043131 LH
.359 14.75 4.5 2.5 5.72 80 3.75
Table 11-1: Square Torsion Springs
SPRING PN
(last 3 digits
(A)
WIRE
DIAMETER
inches (B)
LEG 1
inches (C)
LEG 2
inches (D)
COIL ID
inches (E)
# OF
COILS
inches (F)
DEGREES
OPEN
ANGLE (G)
SPRING
WIDTH
inches (H)
