1.29
SPECIFICATIONS
Table 1-172: Chaincase
Center distance in/cm 8.373/21.27
Reverse type PERC
Table 1-173: Fluids and capacities
Fuel gal/l 10.8/40.9
Oil qts/l 3.4/3.2
Coolant qts/l 5.6/5.3
Chaincase oz/ml 11/325.3
Brake fluid type DOT 4
Table 1-174: IQ Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm 1/2.5
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
7/8” - 1 1/8” (2.2 - 2.9cm)
Table 1-175: M-10 Track
Width in/cm 15/38
Length in/cm 128/325
Lug height in/cm 1.25/3.2
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
.875-1.13/2.2-2.9
Table 1-176: Front Suspension
Suspension type IQ 42.5
IFS shocks Arvin/7042258*
IFS spring rate lbs-in/kg-mm 100/1.8
Spring installed length in/cm 10.55/26.8
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/mm 2.25±.31/5.7±.79
Toe in/mm 0-.12/0-3.0
Table 1-177: M-10 Rear Suspension
Suspension type M-10 128
Front track shock Fox/7043123*
Front track shock spring rate
lbs-in/kg-mm
180/3.2
Spring installed length in/cm 8.75/22.2
Rear track shock Fox/7043190*
Lower outer lbs-in/kg-mm 715/12.8
Lower inner lbs-in/kg-mm 425/7.6
Upper lbs-in/kg-mm 273/4.9
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-178: IQ Rear Suspension
Suspension type IQ 121
Front track shock (FTS) Arvin/7043178*
FTS spring rate
lbs-in/kg-mm
130-270/2.3-4.8
FTS spring installed length
in/cm
7.97/20.2
Rear track shock Fox/7043177*
Rear idler wheel travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-179: Torsion spring
Torsion spring PNs
(LH/RH)
7043070/7043071
Torsion spring diameter in/mm
.347/8.8
Torsion spring tail angle
80_
Table 1-180: Dimensions
Width in/cm 47.25/120
Length in/cm 115/292
Height in/cm 47/119
Est dry weight lb/kg 480/217.9
Table 1-181: Electrical
Stator output 400w@4000RPM
Ignition timing @ 9.6-12.7%
throttle
16_@3500
Spark plug gap in/mm .025/.64
Spark plug Champion RN57YCC
