SPECIFICATIONS
Table 1-202: IQ Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm 1.25/3.2
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
.875-1.125/2.2-.9
Table 1-203: M-10 Track
Width in/cm 15/38
Length in/cm 128/325
Lug height in/cm 1.25/3.2
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
7/8” - 1 1/8” (2.2 - 2.9cm)
Table 1-204: Front Suspension
Suspension type IQ 42.5
IFS shocks Arvin/7042258*
IFS spring rate lbs-in/kg-mm 120/2.2
Spring installed length in/cm 11.17/28.4
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/cm 2.25±.31/5.7±.79
Toe in/mm 0-.12/0-3.0
Table 1-205: IQ Rear Suspension
Suspension type IQ 121
Front track shock (FTS) Arvin/7043178*
FTS spring rate
lbs-in/kg-mm
130-270/2.3-4.8
FTS spring installed length
in/cm
7.97/20.2
Rear track shock Fox/7043177*
Rear vertical travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-206: IQ Torsion spring
Torsion spring PNs
(LH/RH)
7043070/7043071
Torsion spring diameter in/mm
.347
Torsion spring tail angle
80_
Table 1-207: M-10 Rear Suspension
Suspension type M-10 128
Front track shock (FTS) Fox/7043123
FTS spring rate
in-lbs/kg-mm
160/2.9
FTS spring installed length
in/cm
8/20.3
Rear track shock Fox/7043190*
Lower outer spring lbs-in/
kg-mm
715/12.8
Lower inner spring lbs-in/
kg-mm
425/7.6
Upper spring lbs-in/kg-mm 273/4.9
Rear ravel in/cm 13/33
* notes that shock is rebuildable
Table 1-208: Dimensions
Width in/cm 47.25/120
Length in/cm 117/297
Height in/cm 47/119
Est dry weight lb/kg 524/237.9
Table 1-209: Electrical
Stator output 400w@4000RPM
Ignition timing @ 9.6-12.7%
throttle
16_@3500
Spark plug gap in/mm .025/.64
Spark plug Champion RN57YCC
