1.41
SPECIFICATIONS
Table 1-256: Chaincase
Center distance in/cm 7.92/20.1
Reverse type PERC
Table 1-257: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l Air
Chaincase oz/ml 9/266.2
Brake fluid type DOT 4
Table 1-258: Track
Width in/cm 15/38
Length in/cm 136/345
Lug height in/cm 1.25/3.2
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.375-.50/1-1.3
Table 1-259: Front Suspension
Suspension type Edge RMK
IFS shocks Arvin/7042197
IFS spring rate
lbs-in/kg-mm
80/1.4
Spring installed length in/cm 9.75/24.8
Front vertical travel in/cm 7.6/19.3
Ski center distance in/cm 41/104
Camber in/mm .735±.31/18.7±7.9
Toe in/mm 0-.12
Table 1-260: Rear Suspension
Suspension type
Edge RMK
Front track shock
Arvin/7042085
FTS spring rate
lbs-in/kg-mm
170/3.0
FTS spring installed length
in/cm
7.375/18.7
Rear track shock
7042058
Rear travel in/cm 13.8/35.1
* notes that shock is rebuildable
Table 1-261: Torsion spring
Torsion spring PNs
(LH/RH)
7041627/7041628
Torsion spring diameter in/mm
.347/8.8
Torsion spring tail angle
77_
Table 1-262: Dimensions
Width in/cm 45.5/115.6
Length in/cm 124/315
Height in/cm 48/121.9
Est dry weight lb/kg 475/215.7
Table 1-263: Electrical
Ignition timing
27_@3000 RPM
14_@6500 RPM
Spark plug gap in/mm .028/.71
Spark plug NGK BR9ES
Voltage regulator/output 240 watts
Magneto pulse 6
CDI marking CU7236
