25
FEATURES AND CONTROLS
Component Locations
Instrument Cluster
You r RANGER is equipped with an instrument cluster that senses vehi-
cle speed from the right front wheel. The instrument cluster measures
distance in miles as well as time, hours of operation and engine RPM.
Refer to page 34 for the location of the instrument cluster.
NOTE: In addition to showing vehicle speed, the speedometer needle flashes
when a low fuel condition exists.
Rider
Information
Center
Speedometer
Speedometer
Needle
Park Brake
Indicator
To Next Page
