HANDLEBAR ADJUSTMENTS
HANDLEBAR ANGLE
1. Securing the handlebar clamp bolts
q
with an Allen wrench, loosen each of
the four nuts (located on each bolt’s opposite end).
CAUTION
Take care to avoid damaging hand warmer/brake switch wires when moving
components.
2. Adjust the handlebar forward or rearward to the desired angle.
3. Be sure the handlebar, brake lever and throttle lever operate smoothly and
do not hit the gas tank, windshield or any other part of the machine when
turned fully to the left or right. If necessary, adjust the left and right hand
controls. See page 46.
4. Tighten the handlebar clamp nuts. Do not over-torque.
TORQUE
Handlebar Clamp Nuts
7 ft-lbs (9.5 N·m)
48
THE PERFECT FIT
