TOE HOLD POSITION ADJUSTMENT
1. Locate two toe hold mounting bolts toward the front of the tunnel and running
boards.
2. Select the mounting position that best fits the rider’s boot or riding style.
a. Option
q
: Low
b. Option
w
: Mid
c. Option
e
: High
d. Option 4: Completely removed
NOTICE
Toe hold partially hidden for clarity.
3. Reinstall two toe hold mounting bolts. Torque bolts to specification.
TORQUE
Toe Hold Mounting Bolts:
8.9 ft-lbs (12 N·m)
105
THE PERFECT FIT
