38
THE PERFECT FIT
PRO X Rear Suspension Adjustments
Rear Torsion Sprin g Tension
To adjust rear torsion spring tension, rotate the three-position cam
using the engine spark plug tool. Different rate torsion springs are
available if a firmer ride is desired. Contact your dealer for more
information.
The following information is provided only as a guideline t o be used
for initial suspension set-up. Your set-up may vary based on your
desired riding style.
1a - Turn the knob to the left for a softer ride
1b - Turn the knob to the right for a stiffer ride
2a - Soft Tension - long end of cam to front
2b - Medium tension - short end of cam up
2c - Firm tension - long end of cam up
2b
2a
2c
1a
1b
