BODY/STEERING/SUSPENSION
5.2
TORQUE SPECIFICATIONS
ITEM TORQUE VALUE
Front A-Arm Attaching
Bolt
30 ft. lbs. (41 Nm)
Front A-Arm Ball Joint
Stud Nut
25 ft. lbs. (35 Nm)
Handlebar Adjuster
Block
10-12 ft. lbs. (14-17
Nm)
Master Cylinder 45-55 in. lbs. (5.2-6.3
Nm)
Rear Shock Bolt
(upper)
25 ft. lbs. (34 Nm)
Rear Shock Bolt
(lower)
25 ft. lbs. (34 Nm)
Rear Wheel Hub Nut 110 ft. lbs. (150 Nm)
Rear Wheel Nuts 35 ft. lbs. (48 Nm)
Upper Stabilizer
Support Nut
17 ft. lbs. (24 Nm)
Upper Control Arm
Mounting Bolt
35 ft. lbs. (48 Nm)
Lower Control Arm
Mounting Bolt
30 ft. lbs. (41 Nm)
Upper Wheel Bearing
Carrier Bolt
35 ft. lbs. (48 Nm)
Lower Wheel Bearing
Carrier Bolt
30 ft. lbs. (41 Nm)
Strut Rod Retaining
Nut (Top)
15 ft. lbs. (21 Nm)
Strut Casting Pinch
Bolt
15 ft. lbs. (21 Nm)
TieRodEndJamNut 12-14 ft. lbs. (17-19
Nm
TieRodEndCastle
Nut
40-45 ft. lbs. (54-61
Nm)
TieRodEndAttaching
Bolt
25-30 ft. lbs. (35-41
Nm)
NOTE: Refer to exploded views throughout this
chapter for identification and location of components.
SPECIAL TOOLS
TOOL DESCRIPTION PART NUMBER
Strut and Ball Joint
Tool Set
2870871
Shock Spanner
Wrench
2870872
Shock Spring
Compressor Tool
2870623
Strut Spring
Compressor Tool (LH)
2871573
Strut Spring
Compressor Tool (RH)
2871574
