GENERAL INFORMATION
2.7
LUBRICATION, CONT.
Item Lube Rec. Method Frequency*
4. Front Gearcase Polaris Demand Drive Hub Fluid
(PN 2871654)
Drain completely. Add lube to spe-
cified quantity.
Change annually©
5. Rear Gearcase Polaris Gear Drive Fluid
(PN 2871477)
Drain completely. Add lube to spe-
cified quantity.
Change annually©
6. Rear Prop
Shaft U--Joints
Polaris Premium U --Joint Lube
(PN 2871551)
Locate fittings and grease and
grease with grease gun.
Semi--annually¡
7. Rear Prop
Shaft Yoke
Polaris Premium U --Joint Lube
(PN 2871551)
Locate fittings and grease with
grease gun.
Semi--annually¡
8. Front Prop
Shaft U--Joints
Polaris Premium U --Joint Lube
(PN 2871551)
Locate fittings and grease with
grease gun.
Semi--annually¡
9. Front Prop
Shaft Yoke
Polaris Premium U --Joint Lube
(PN 2871551)
Drain completely. Add lube to spe-
cified quantity.
Semi--annually¡
10. Middle Gearcase Polaris Gear Drive Fluid
(PN 2871477)
Polaris Gear Drive Fluid Semi--annually¡
* More often under severe use, such as operated in water or under severe loads.
¡ Semi-annually or 50 hours of operation (refer to Maintenance Schedule for additional information)
© Annually or 100 hours of operation (refer to Maintenance Schedule for additional information)
¢ Grease conforming to NLGI No. 2, such as Polaris Premium All Season Grease, Conoco Superlube M or
Mobilegrease Special
Front Gearcase (4x4 & 6x6) Rear Gearcase (All Models)
Rear Prop Shaft Front Prop Shaft (4x4 & 6x6)
6. U--Joints
7. Yoke 8. U--Joints
9. Yoke
4. Fill Plug
5. Fill Plug
Drain Plug Drain Plug
10. Fill Plug
Drain Plug
MIddle Gearcase (6x6 )
