TRANSMISSION
8.20
2X4 TRANSMISSION EXPLODED VIEW, CONT.
Ref. Qty. Description Ref. Qty. Description
1 Asm., 2x4 Tr ansmission 35. 1 Sprocket, 24T
1. 1 Washer, Flat 36. 1 Washer
2. 5 Screw 37. 1 Washer
3. 1 Cover 38. 1 Gear, 30T
4. 1 Pawl, Detent 39. 1 Gear, 37T
5. 1 O--Ring 40. 1 Gear, 47T
6. 1 Shaft, Shift 41. 4 Screw
7. 1 Seal 42. 1 Cover, Bearing
8. 1 Gear, 31T 43. 1 Ring, Retaining
9. 1 Gearcase, Main 44. 1 Bearing, Ball
10. 1 Tube, Vent 45. 1 Shaft, 10T
11. 4 Pipe, Knock 46. 1 Washer, Thrust
12. 1 Drum, Shift 47. 1 Button, Thrust
13. 4 Bearing, Ball 48. AR Shim
14. 1 Chain, Silent 49. 1 Gearcase, Cover, Front
15. 1 Gear, 15T 50. 1 Plug
16. 1 Sprocket, 16T 51. 1 Washer
17. 1 Gear, 31T 52. AR Shim
18. 1 Shaft, Input 53. 1 Shaft, Output, Rear
19. 3 Bearing, Ball 54. 1 Gear, 31T
20. 1 Asm., Input Shaft (Incl. 15--18) 55. 2 Screw
21. 1 Cover, Main, LH 56. 1 Deflector, Oil
22. 17 Screw 57. 1 O--Ring
23. 1 Seal 58. 1 Gear, 16T
24. 2 Pin, Dowel 59. 1 Disc, Lockout
25. 2 Fork 60. 1 Detent, Star
26. 1 Rail, Shift Shaft 61. 1 O--Ring
27. 4 Pin, Dowel 62. 1 Plug, Oil Fill
28. 2 Dog, Engagement 63. 1 Washer
29. 2 Ring, Retaining 64. 1 Spring, Compression
30. 1 Washer 65. 1 Switch
31. 1 Gear, 33T 66. 1 Ring, Retaining
32. 2 Bearing, Needle 67. 1 Nut, Nylok
33. 1 Shaft, Reverse 68. 1 Bellcrank
34. 1 Bearing, Needle 69. 1 Nut, FLEXLOC
