TOE ALIGNMENT INSPECTION
WARNING
Severe injury or death can result from improper toe alignment and adjustment.
Do not attempt to adjust tie rod alignment. All tie rod adjustments should be
performed by an authorized POLARIS dealer or other qualified service facility.
1. Place machine on a smooth level surface and set steering wheel in a straight
ahead position. Secure the steering wheel in this position.
2. Place a chalk mark on the center line of the front tires approximately 25.4 cm
(10″) from the floor or as close to the hub/axle center line as possible
q
.
NOTE
It is important the height of both marks be equally positioned to get an accurate
measurement.
3. Measure the distance between the marks and record the measurement. Call
this measurement “2”.
81
MAINTENANCE
