Polaris Alpha User Manual

49
2. Configure the input stream options as follows. Press the OK button to return to the STRSVR
dialog when finished.
Field
Description
Example
Port
Select the COM port for base data input
COM7
Bitrate (bps)
Serial port data input bit rate.
115200
Byte Size
Byte Size depends on serial settings.
8 bits
Parity
Parity depends on serial settings.
None
Stop Bits
Stop Bits depends on serial settings.
1 bit
Flow Control
Flow control depends on serial settings.
None
Table A-2-1
Figure A-2-3
3. Setup an output stream of type "NTRIP Server" and press the "Opt" button to set the output
stream options.
Figure A-2-4

Polaris Alpha Specifications

General

Frequency Range	20 MHz to 6 GHz
Instantaneous Bandwidth	40 MHz
Dynamic Range	80 dB
Power Supply	12V DC
Interface	Ethernet
