6-4 RTK Application Scenarios In Detail
This section we go into details on application scenarios.
Table 6-1
6-4-1 Short Baseline Test Setup
Base
TTL mode / switch on A
Rover
TTL mode / switch on B
Micro-USB
cable
Micro-USB
cable
6-pin 3 wire for Base-to-Rover (sec. 3-4-1)
Setup for Special Short Baseline Experiment
RTK
antenna
RTK
antenna
. . .
Alpha RTK Alpha RTK
Figure 6-10
Configure one Alpha as rover (cf. section 6-2). Configure the other Alpha as a base with option "Set
Receiver to Self-Survey Approx. Coordinate for 60sec Each Time Powering Up" (cf. section 6-3-2)
